Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 06/21/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x4PostHeavyDutyRackAssemblyKit

• 1xAssemblyinstructions

• 1xPackof50ScrewsandNuts

4POSTRACKHD

45U 3300 lbs 4 Post Open Server Equipment Rack - Flat Pack

Tools Required

• 2x14mmwrench

Assembly

1. Laytheverticalrailsfacedown.Atoneend,placeatop/bottomrail

andinsertthreehexheadboltsandfastenwiththreeheadnuts.

2. Installasecondtop/bottomrailattheotherendoftheverticalrail.

3. RepeatStep2toattachthesecondverticalrail.RepeatSteps1to

3toassembletheotherside.

4.Connecttheverticalrailstogetherusingthejoinbrackets.

Insertthehooksintotheslotsontheverticalrails.Inserttwo

hexheadboltsandfastenwithtwoheadnutsforeachside.



5. Securelyattachthejoinbracketsatthetopandbottomendson

asinglesiderst.Thenreversetherackandrepeatthesamesteps

ontheotherside.

 

6.Finishedassemblyofrack.



7.Standuptheframeandcheckthatalltheboltsaretightened.

 

BottomofRack

TopofRack

WARNING! Topreventbodilyinjury,pleaseensurethattherack

isinstalledinastructurallysoundenvironmentwithaleveloor

andthatallhardwarehasbeenassembledsecurely,andcheckedfor

stabilitybeforeloadingequipment.Wheninstallingequipmentinto

therack,startfromthebottomoftherackrstandmoveupwards,

keepingtheheaviestequipmentatthebottomtoavoidasituation

wheretherackbecomestop-heavy.

1 2
